床身上更大回轉直徑

Swing over bed

mm

360

400

500

橫滑板上更大回轉直徑

Swing over cross slide

mm

190

210

260

更大工件長度

Distance between centers

mm

750/1000/1500/2000

750/1000/1500/2000

750/1000/1500/2000

主軸孔徑范圍

Spindle bore

mm

52(Optional 80)

52(Optional 80)

52(Optional 80)

主軸孔徑錐度

Spindle bore taper

-

MT6

MT6

MT6

主軸鼻端型號

Spindle nose type

-

C6

C6

C6

主軸轉速級數

Spindle speed steps

-

Manual 2 steps

Manual 2 steps

Manual 2 steps

主軸轉速范圍

Spindle speed range

rpm

L:100-500 H:500-1800  (Optional 90-1800 stepless)

L:100-500 H:500-1800  (Optional 90-1800 stepless)

L:100-500 H:500-1800  (Optional 90-1800 stepless)

刀架類型

Turret/tool post

-

Electric4 position

Electric4 position

Electric4 position

刀具尺寸

Tool size

mm

20 x 20

25 x 25

25 x 25

X軸行程

X axis travel

mm

200

230

280

Z軸行程

Z axis travel

mm

750/1000/1500/2000

750/1000/1500/2000

750/1000/1500/2000

X軸快速進給速度

X axis rapid traverse

mm/min

6000

6000

6000

Z軸快速進給速度

Z axis rapid traverse

mm/min

8000

8000

8000

尾座套筒直徑

Tailstock quill diameter

mm

65

65

65

尾座套筒錐度

Tailstock quill taper

-

MT4

MT4

MT5

尾座套筒行程

Tailstock quill travel

mm

130

130

130

主軸電機

Main spindle motor

kw

4

4

5.5

冷卻泵電機

Coolant pump motor

kw

0.09

0.09

0.09

機床重量

Machine weight

Weight for 750

kg

1600

1700

1800

Weight for1000

kg

1700

1800

1900

Weight for 1500

kg

1800

1900

2000

Weight for 2000

kg

1900

2000

2100

外形尺寸

Overall dimension

Dimension for 750

mm

2200x1600x1650

2200x1650x1700

2200x1700x1750

Dimension for1000

mm

2500x1600x1650

2500x1650x1700

2500x1700x1750

Dimension for1500

mm

3000x1600x1650

3000x1650x1700

3000x1700x1750

Dimension for2000

mm

3500x1600x1650

3500x1650x1700

3500x1700x1750
